Volume 51,Issue 6,2022 Table of Contents
2022, 51(6):1933-1941.
DOI: 10.12442/j.issn.1002-185X.E20210010
Abstract:
Four types of Y2O3 partially stabilized ZrO2 (YSZ)-based agglomerated powder containing no bonding phase, Al2O3, yttrium aluminum garnet (YAG), and MgAl2O, labeled as B0, B1, B2, and B3, respectively, were prepared by spray granulation. And, the flow ability, apparent density and particle size distribution of those powders were investigated. Besides, the deposition efficiency (DE) and bonding mechanism of the four types of agglomerated powder prepared by atmospheric plasma spraying (APS) were analyzed. The results show that, compared with B0 powder, the flowability of B1, B2 and B3 powder is reduced by 6.94%, 5.15% and 25.2%, respectively, the apparent density is reduced by 2.85%, 2.19% and 7.67%, respectively, and the proportion of large-size agglomerated powder is increased by 15.82%, 6.65% and 29.75%, respectively. The DE of B1, B2 and B3 powder is increased by 75.80%, 181.49% and 59.21%, respectively, and the main reason for the improvement of DE is the adhesion and wrapping effect of the bonding phase. Because YAG has the lowest melting point and moderate particle size, B2 powder has the best flowability, the maximum apparent density, and the smallest proportion of large particles, which accordingly results in the strongest adhesion and wrapping effect and eventually leads to the highest DE.
Four types of Y2O3 partially stabilized ZrO2 (YSZ)-based agglomerated powder containing no bonding phase, Al2O3, yttrium aluminum garnet (YAG), and MgAl2O, labeled as B0, B1, B2, and B3, respectively, were prepared by spray granulation. And, the flow ability, apparent density and particle size distribution of those powders were investigated. Besides, the deposition efficiency (DE) and bonding mechanism of the four types of agglomerated powder prepared by atmospheric plasma spraying (APS) were analyzed. The results show that, compared with B0 powder, the flowability of B1, B2 and B3 powder is reduced by 6.94%, 5.15% and 25.2%, respectively, the apparent density is reduced by 2.85%, 2.19% and 7.67%, respectively, and the proportion of large-size agglomerated powder is increased by 15.82%, 6.65% and 29.75%, respectively. The DE of B1, B2 and B3 powder is increased by 75.80%, 181.49% and 59.21%, respectively, and the main reason for the improvement of DE is the adhesion and wrapping effect of the bonding phase. Because YAG has the lowest melting point and moderate particle size, B2 powder has the best flowability, the maximum apparent density, and the smallest proportion of large particles, which accordingly results in the strongest adhesion and wrapping effect and eventually leads to the highest DE.
2022, 51(6):1942-1948.
DOI: 10.12442/j.issn.1002-185X.20210370
Abstract:
To improve the corrosion resistance of magnesium alloys, super-hydrophobic (SH) coating was fabricated on the surface of ZK60 magnesium alloy coated with layered double hydroxides (LDHs) film. The electric field was introduced in the coating preparation process, and the influences of working current density on the characteristics of the coatings were researched. The results indicate that the working current densities significantly affect the microstructure of the LDHs films, which has an important impact on the hydrophobicity of the SH coatings. When the working current density is 25 mA/cm2, the SH coating presents a homogenous micro-nano structure and super-hydrophobicity. The corrosion current density of the SH coating (Icorr =9×10-7 A·cm-2) is two orders of magnitude lower than that of the ZK60 substrate (Icorr =3×10-5 A·cm-2), indicating excellent corrosion resistance.
To improve the corrosion resistance of magnesium alloys, super-hydrophobic (SH) coating was fabricated on the surface of ZK60 magnesium alloy coated with layered double hydroxides (LDHs) film. The electric field was introduced in the coating preparation process, and the influences of working current density on the characteristics of the coatings were researched. The results indicate that the working current densities significantly affect the microstructure of the LDHs films, which has an important impact on the hydrophobicity of the SH coatings. When the working current density is 25 mA/cm2, the SH coating presents a homogenous micro-nano structure and super-hydrophobicity. The corrosion current density of the SH coating (Icorr =9×10-7 A·cm-2) is two orders of magnitude lower than that of the ZK60 substrate (Icorr =3×10-5 A·cm-2), indicating excellent corrosion resistance.
2022, 51(6):1949-1956.
DOI: 10.12442/j.issn.1002-185X.20210279
Abstract:
The pure Ti with different initial grain sizes which was annealed at 923 and 1023 K for 1 h was processed by ECAP at room temperature. The influence of initial grain size on microstructure and properties of ECAPed pure Ti was investigated by TEM, EBSD, tensile tests and microhardness tests at room temperature. The twinning behavior and deformation mechanism of pure Ti were also discussed during the ECAP. The results show that the initial grain size of pure Ti increases with increasing the annealing temperature. The grain refinement effect of pure Ti annealed at 1023 K is more significant than that of pure Ti annealed at 923 K after 1 pass of ECAP, while the microstructure of pure Ti annealed at 923 K is finer and more uniform than that of pure Ti annealed at 1023 K after 4 passes of ECAP. With the increase of ECAP pass, the yield stress increases, especially after 1 pass with more than 100% implication. The larger the initial grain size, the greater the stress increase. The deformation mechanisms of pure Ti during the ECAP include dislocation slips and deformation twinning, and with the increase of the initial grain size, the number of twins increases.
The pure Ti with different initial grain sizes which was annealed at 923 and 1023 K for 1 h was processed by ECAP at room temperature. The influence of initial grain size on microstructure and properties of ECAPed pure Ti was investigated by TEM, EBSD, tensile tests and microhardness tests at room temperature. The twinning behavior and deformation mechanism of pure Ti were also discussed during the ECAP. The results show that the initial grain size of pure Ti increases with increasing the annealing temperature. The grain refinement effect of pure Ti annealed at 1023 K is more significant than that of pure Ti annealed at 923 K after 1 pass of ECAP, while the microstructure of pure Ti annealed at 923 K is finer and more uniform than that of pure Ti annealed at 1023 K after 4 passes of ECAP. With the increase of ECAP pass, the yield stress increases, especially after 1 pass with more than 100% implication. The larger the initial grain size, the greater the stress increase. The deformation mechanisms of pure Ti during the ECAP include dislocation slips and deformation twinning, and with the increase of the initial grain size, the number of twins increases.
2022, 51(6):1957-1963.
DOI: 10.12442/j.issn.1002-185X.20210316
Abstract:
The effect of cooling medium on microstructure evolution, variant selection and texture inheritance along with mechanical properties in a recrystallized commercially pure Ti sheet after β-solution treatment was investigated by combined use of optical microscopy (OM), electron channeling contrast (ECC) imaging, electron backscatter diffraction (EBSD) techniques, transmission electron microscopy (TEM) and micro-hardness test. It is found that with the decrease of cooling rate, fine needle-like α′ martensite (in water and liquid nitrogen), Widmanst?tten (in air), and coarse-grain microstructures (in furnace) are observed in turn. Additionally, the faster cooling rate results in a finer transformed structure accompanied with an attendant higher hardness value. Analyses for crystallographic orientations reveal that the Burgers orientation relationship (BOR) is strictly obeyed during the β→α cooling except for the β-furnace-cooled specimen with appearance of other misorientations disobeying the BOR. As for texture characteristics, firstly, the texture distribution is largely scattered compared with the initial one and new orientation components of <0001>//TD and <
The effect of cooling medium on microstructure evolution, variant selection and texture inheritance along with mechanical properties in a recrystallized commercially pure Ti sheet after β-solution treatment was investigated by combined use of optical microscopy (OM), electron channeling contrast (ECC) imaging, electron backscatter diffraction (EBSD) techniques, transmission electron microscopy (TEM) and micro-hardness test. It is found that with the decrease of cooling rate, fine needle-like α′ martensite (in water and liquid nitrogen), Widmanst?tten (in air), and coarse-grain microstructures (in furnace) are observed in turn. Additionally, the faster cooling rate results in a finer transformed structure accompanied with an attendant higher hardness value. Analyses for crystallographic orientations reveal that the Burgers orientation relationship (BOR) is strictly obeyed during the β→α cooling except for the β-furnace-cooled specimen with appearance of other misorientations disobeying the BOR. As for texture characteristics, firstly, the texture distribution is largely scattered compared with the initial one and new orientation components of <0001>//TD and <
2022, 51(6):1964-1971.
DOI: 10.12442/j.issn.1002-185X.20210311
Abstract:
The pure titanium prepared by selective laser melting (SLM) was modified by equal channel angular pressing (ECAP). The pure titanium prepared by SLM was subjected to single-pass deformation modification at room temperature by a die with the angle of Φ=120° and ψ=20° between two channels, and its microstructure and mechanical properties were evaluated. The results show that the microstructure of SLM+ECAP pure Ti sample is refined, the grain size decreases from 13 μm to 7 μm, and the dislocation density increases. During the ECAP deformation process, twinning and continuous dynamic recrystallization (CDRX) occur simultaneously. The appearance of tensile and compression twin and the increase of dislocation density together promote the microhardness of SLM+ECAP pure Ti samples, increased by 13%, and YS and UTS are increased by 18% and 20.4% respectively, while the elongation decreases slightly.
The pure titanium prepared by selective laser melting (SLM) was modified by equal channel angular pressing (ECAP). The pure titanium prepared by SLM was subjected to single-pass deformation modification at room temperature by a die with the angle of Φ=120° and ψ=20° between two channels, and its microstructure and mechanical properties were evaluated. The results show that the microstructure of SLM+ECAP pure Ti sample is refined, the grain size decreases from 13 μm to 7 μm, and the dislocation density increases. During the ECAP deformation process, twinning and continuous dynamic recrystallization (CDRX) occur simultaneously. The appearance of tensile and compression twin and the increase of dislocation density together promote the microhardness of SLM+ECAP pure Ti samples, increased by 13%, and YS and UTS are increased by 18% and 20.4% respectively, while the elongation decreases slightly.
2022, 51(6):1972-1978.
DOI: 10.12442/j.issn.1002-185X.20210354
Abstract:
The corrosion, wear and tribocorrosion behavior of a new biomedical Ti-20Zr-10Nb alloy was investigated using electrochemical measurements, tribological tests and scanning electron microscopy (SEM). Potentiodynamic polarization tests show that the corrosion potential (Ecorr) shifts towards negative values and that the corrosion current density (icorr) is increased by two orders of magnitude; these trends differ from those observed with static corrosion. The wear and tribocorrosion results indicate that the wear volume of the Ti-20Zr-10Nb alloy increases with increasing applied load. The contribution of mechanical wear to the material loss of tribocorrosion is greater than that of corrosion. However, the friction coefficients obtained under conditions of electrochemical corrosion are lower than that obtained only under wear. Through observation of the wear crack, it is determined that abrasive wear mechanism is the main mechanism of tribocorrosion. The effect of abrasive particles on the wear and tribocorrosion behavior is considered, and it is found that material loss increases due to particle damage.
The corrosion, wear and tribocorrosion behavior of a new biomedical Ti-20Zr-10Nb alloy was investigated using electrochemical measurements, tribological tests and scanning electron microscopy (SEM). Potentiodynamic polarization tests show that the corrosion potential (Ecorr) shifts towards negative values and that the corrosion current density (icorr) is increased by two orders of magnitude; these trends differ from those observed with static corrosion. The wear and tribocorrosion results indicate that the wear volume of the Ti-20Zr-10Nb alloy increases with increasing applied load. The contribution of mechanical wear to the material loss of tribocorrosion is greater than that of corrosion. However, the friction coefficients obtained under conditions of electrochemical corrosion are lower than that obtained only under wear. Through observation of the wear crack, it is determined that abrasive wear mechanism is the main mechanism of tribocorrosion. The effect of abrasive particles on the wear and tribocorrosion behavior is considered, and it is found that material loss increases due to particle damage.
2022, 51(6):1979-1985.
DOI: 10.12442/j.issn.1002-185X.E20210007
Abstract:
The effect of the shot peening intensity on the surface integrity of TA15 titanium alloy hot extruded profile was numerically and experimentally studied. The surface roughness and residual stress distribution obtained by the numerical simulation were compared with the shot peening experimental results, and the reliability of the established finite element model was verified. The effects of shot peening intensity on the microhardness and microstructure of the material surface were investigated. The experimental results show that the compressive residual stress layer with a maximum value of 558~764 MPa and a depth of 115~151 μm was introduced into the surface of TA15 titanium alloy profile after shot peening. The plastic deformation occurs on the material surface, the grain is refined, the dislocation density and the hardness of the material surface increase. The hardened layer with a depth of 100~150 μm forms, and the surface roughness increases. The increase of the shot peening intensity increases the maximum compressive residual stress, the depth of the compressive residual stress layer and the surface hardness. However, the increase is not obvious when the intensity exceeds 0.188 mmA, and the cracks might appear on the material surface. Moreover, at the intensity of 0.222 mmA, the residual stress relaxation occurs on the material surface due to the folding defect, which reduces the surface integrity of the material.
The effect of the shot peening intensity on the surface integrity of TA15 titanium alloy hot extruded profile was numerically and experimentally studied. The surface roughness and residual stress distribution obtained by the numerical simulation were compared with the shot peening experimental results, and the reliability of the established finite element model was verified. The effects of shot peening intensity on the microhardness and microstructure of the material surface were investigated. The experimental results show that the compressive residual stress layer with a maximum value of 558~764 MPa and a depth of 115~151 μm was introduced into the surface of TA15 titanium alloy profile after shot peening. The plastic deformation occurs on the material surface, the grain is refined, the dislocation density and the hardness of the material surface increase. The hardened layer with a depth of 100~150 μm forms, and the surface roughness increases. The increase of the shot peening intensity increases the maximum compressive residual stress, the depth of the compressive residual stress layer and the surface hardness. However, the increase is not obvious when the intensity exceeds 0.188 mmA, and the cracks might appear on the material surface. Moreover, at the intensity of 0.222 mmA, the residual stress relaxation occurs on the material surface due to the folding defect, which reduces the surface integrity of the material.
2022, 51(6):1986-1992.
DOI: 10.12442/j.issn.1002-185X.20210383
Abstract:
3D through-hole Pb-Ca-Sn anode was prepared which may be a promising anode with excellent performance for copper electrowinning. And the electrochemical properties of 3D through-hole Pb-Ca-Sn anode and Pb-Ca-Sn anode were studied by galvanostatic polarization, electrochemical impedance spectroscopy, anodic polarization and double-Slope Tafel carried out in 160 g/L H2SO4 solution at 45 °C. Besides, the micro-morphology, element distribution and phase composition of the oxide layer were investigated. Results show that compared with the traditional Pb-Ca-Sn, 3D through-hole Pb-Ca-Sn anode shows much lower anodic potential, higher exchange current density and better electrocatalytic activity. These characteristics are related to its excellent 3D through-hole structure, which increases the oxygen evolution surface area of the anode. Furthermore, the content of β-PbO2 and PbSO4 in the oxide layer of 3D through-hole Pb-Ca-Sn is higher and lower than those of Pb-Ca-Sn, respectively.
3D through-hole Pb-Ca-Sn anode was prepared which may be a promising anode with excellent performance for copper electrowinning. And the electrochemical properties of 3D through-hole Pb-Ca-Sn anode and Pb-Ca-Sn anode were studied by galvanostatic polarization, electrochemical impedance spectroscopy, anodic polarization and double-Slope Tafel carried out in 160 g/L H2SO4 solution at 45 °C. Besides, the micro-morphology, element distribution and phase composition of the oxide layer were investigated. Results show that compared with the traditional Pb-Ca-Sn, 3D through-hole Pb-Ca-Sn anode shows much lower anodic potential, higher exchange current density and better electrocatalytic activity. These characteristics are related to its excellent 3D through-hole structure, which increases the oxygen evolution surface area of the anode. Furthermore, the content of β-PbO2 and PbSO4 in the oxide layer of 3D through-hole Pb-Ca-Sn is higher and lower than those of Pb-Ca-Sn, respectively.
2022, 51(6):1993-1998.
DOI: 10.12442/j.issn.1002-185X.20210301
Abstract:
Heterojunction solar cells (HSCs) with the structure of p-Si/n-ZnO nanorod (NR) arrays were prepared by synthesizing a ZnO NR array film on patterned p-type silicon substrate through a low temperature hydrothermal method. ITO and Al films as the front and back contact electrode layers were deposited by DC-magnetron sputtering, respectively. The influences of various factors, such as annealing temperature for seed layer and hydrothermal synthesis time for ZnO NR arrays, on the crystal structure, surface morphology, and optical property of the ZnO NR array film were investigated. Results show that the optimized short-circuit current density and allover energy conversion efficiency of the p-Si/n-ZnO nanorod array HSCs are 11.475 mA·cm-2 and 2.0%, respectively. Compared with those of p-Si/n-thin film ZnO solar cell, the photovoltaic properties of the p-Si/n-ZnO nanorod array HSCs are improved significantly.
Heterojunction solar cells (HSCs) with the structure of p-Si/n-ZnO nanorod (NR) arrays were prepared by synthesizing a ZnO NR array film on patterned p-type silicon substrate through a low temperature hydrothermal method. ITO and Al films as the front and back contact electrode layers were deposited by DC-magnetron sputtering, respectively. The influences of various factors, such as annealing temperature for seed layer and hydrothermal synthesis time for ZnO NR arrays, on the crystal structure, surface morphology, and optical property of the ZnO NR array film were investigated. Results show that the optimized short-circuit current density and allover energy conversion efficiency of the p-Si/n-ZnO nanorod array HSCs are 11.475 mA·cm-2 and 2.0%, respectively. Compared with those of p-Si/n-thin film ZnO solar cell, the photovoltaic properties of the p-Si/n-ZnO nanorod array HSCs are improved significantly.
2022, 51(6):1999-2004.
DOI: 10.12442/j.issn.1002-185X.E20210009
Abstract:
TiC/Hastelloy composite has been proposed as one of promising intermediate temperature solid oxide fuel cell interconnects, and the oxidation resistance is one key property for its application. TiC/Hastelloy composites with 50vol% and 58vol% metal matrix were prepared by reactive infiltration method. Results show that high metal content results in the increase in Cr content, which optimizes the oxidation resistance of TiC/Hastelloy composites by promoting formation of continuous Cr2O3 layer to inhibit external diffusion of Ni and Ti. The content of Ti and Ni oxides in oxide scale obviously decreases. The mass gain reduces from 2.03 to 0.55 mg·cm-2. Meanwhile, in order to inhibit the migration of Cr, Co is extra introduced into the composites with 58vol% metal. During the oxidation process, Co and Fe (in metal matrix) show high external diffusion rate through Cr2O3, and generate in-situ CoFe2O4 layer outmost the oxide scale.
TiC/Hastelloy composite has been proposed as one of promising intermediate temperature solid oxide fuel cell interconnects, and the oxidation resistance is one key property for its application. TiC/Hastelloy composites with 50vol% and 58vol% metal matrix were prepared by reactive infiltration method. Results show that high metal content results in the increase in Cr content, which optimizes the oxidation resistance of TiC/Hastelloy composites by promoting formation of continuous Cr2O3 layer to inhibit external diffusion of Ni and Ti. The content of Ti and Ni oxides in oxide scale obviously decreases. The mass gain reduces from 2.03 to 0.55 mg·cm-2. Meanwhile, in order to inhibit the migration of Cr, Co is extra introduced into the composites with 58vol% metal. During the oxidation process, Co and Fe (in metal matrix) show high external diffusion rate through Cr2O3, and generate in-situ CoFe2O4 layer outmost the oxide scale.
2022, 51(6):2005-2010.
DOI: 10.12442/j.issn.1002-185X.20210915
Abstract:
The possible activated slip systems and slip traces of pure coarse-grained magnesium were investigated during cyclic deformation at room temperature. Results show that numerous criss-cross slip traces are observed on the surface of the specimens after cyclic loading. Based on the results of a combinatory analysis for the unit cell orientation and direction of the slip traces, it is determined that the criss-cross slip traces are formed by the intersection of the basal slip traces in the former matrix and the subsequent {
The possible activated slip systems and slip traces of pure coarse-grained magnesium were investigated during cyclic deformation at room temperature. Results show that numerous criss-cross slip traces are observed on the surface of the specimens after cyclic loading. Based on the results of a combinatory analysis for the unit cell orientation and direction of the slip traces, it is determined that the criss-cross slip traces are formed by the intersection of the basal slip traces in the former matrix and the subsequent {
2022, 51(6):2011-2019.
DOI: 10.12442/j.issn.1002-185X.20210343
Abstract:
The effect of minor Gd element on the microstructure and properties of Mg-8Zn-1Mn-3Sn alloy was studied. The results show that Mg-8Zn-1Mn-3Sn-xGd is mainly composed of α-Mg matrix, MgZn2, MgZn, Mg7Zn3, Mg2Sn phase and MgSnGd phase. The MgSnGd phase is a high temperature phase, which is formed firstly during the solidification and changes the solidification process, causing the semi-continuous second phase at the grain boundary to transform into a discontinuous network. The MgSnGd phase has a coherent orientation relationship with the α-Mg matrix, which can be used as a heterogeneous nucleation core to refine grains. The Mg-8Zn-1Mn-3Sn-0.5Gd alloy has the best comprehensive mechanical properties. The mechanical properties of the alloy are significantly improved by adding Gd elements to refine the grains, and the MgSnGd phase pins the grain boundary to hinder the movement of dislocations and the transformation of the second phase of the grain boundary.
The effect of minor Gd element on the microstructure and properties of Mg-8Zn-1Mn-3Sn alloy was studied. The results show that Mg-8Zn-1Mn-3Sn-xGd is mainly composed of α-Mg matrix, MgZn2, MgZn, Mg7Zn3, Mg2Sn phase and MgSnGd phase. The MgSnGd phase is a high temperature phase, which is formed firstly during the solidification and changes the solidification process, causing the semi-continuous second phase at the grain boundary to transform into a discontinuous network. The MgSnGd phase has a coherent orientation relationship with the α-Mg matrix, which can be used as a heterogeneous nucleation core to refine grains. The Mg-8Zn-1Mn-3Sn-0.5Gd alloy has the best comprehensive mechanical properties. The mechanical properties of the alloy are significantly improved by adding Gd elements to refine the grains, and the MgSnGd phase pins the grain boundary to hinder the movement of dislocations and the transformation of the second phase of the grain boundary.
2022, 51(6):2020-2026.
DOI: 10.12442/j.issn.1002-185X.20210360
Abstract:
Based on electron backscattered diffraction (EBSD) and grain growth model of thin film materials, grain sizes and growth thermo-kinetics were investigated during annealing with different heating rates in high-voltage anode aluminum foil. Results show that the grain growth exponent n=4, activation energy Qg=129 kJ/mol and rate constant K=1.28×10-8 m4·s-1 are calculated by the typical isothermal grain growth equation. Based on grain growth model of thin film materials and energy anisotropy, the reasons for the rapid growth of (001) oriented grains are well explained, and a typical 40°<111> misorientation relationship with S-grains is found.
Based on electron backscattered diffraction (EBSD) and grain growth model of thin film materials, grain sizes and growth thermo-kinetics were investigated during annealing with different heating rates in high-voltage anode aluminum foil. Results show that the grain growth exponent n=4, activation energy Qg=129 kJ/mol and rate constant K=1.28×10-8 m4·s-1 are calculated by the typical isothermal grain growth equation. Based on grain growth model of thin film materials and energy anisotropy, the reasons for the rapid growth of (001) oriented grains are well explained, and a typical 40°<111> misorientation relationship with S-grains is found.
2022, 51(6):2027-2032.
DOI: 10.12442/j.issn.1002-185X.20210369
Abstract:
The arc characteristics and droplet transfer behavior in plasma-GMAW-P hybrid welding were investigated. The effect of plasma arc current on GMAW-P arc shape and metal transfer was discussed. The results indicate that the plasma arc will change the electrical conductivity and stress state of GMAW arc to affect the morphology of GMAW arc and droplet transfer behavior. When the plasma arc current is small, the GMAW arc in the base current period basically burns along the wire axis, and the bell-shaped GMAW arc in the peak current period is compressed due to two opposite forces (the electromagnetic force generated by the plasma arc and the wire) in the welding direction. At this time, the drag force of plasma flow and its downward component increase, the droplet transition is promoted, and the detached time of droplet is shortened. When the plasma arc current reaches a certain value, the metal vapor in the atmosphere near the plasma arc increases, and the conductive path of the GMAW arc will be changed to bias the GMAW arc to the plasma arc. At this time, the downward component of the drag force of the plasma flow on the droplet decreases, the promotion of the droplet transition is weakened, and the detached time of droplet is increased.
The arc characteristics and droplet transfer behavior in plasma-GMAW-P hybrid welding were investigated. The effect of plasma arc current on GMAW-P arc shape and metal transfer was discussed. The results indicate that the plasma arc will change the electrical conductivity and stress state of GMAW arc to affect the morphology of GMAW arc and droplet transfer behavior. When the plasma arc current is small, the GMAW arc in the base current period basically burns along the wire axis, and the bell-shaped GMAW arc in the peak current period is compressed due to two opposite forces (the electromagnetic force generated by the plasma arc and the wire) in the welding direction. At this time, the drag force of plasma flow and its downward component increase, the droplet transition is promoted, and the detached time of droplet is shortened. When the plasma arc current reaches a certain value, the metal vapor in the atmosphere near the plasma arc increases, and the conductive path of the GMAW arc will be changed to bias the GMAW arc to the plasma arc. At this time, the downward component of the drag force of the plasma flow on the droplet decreases, the promotion of the droplet transition is weakened, and the detached time of droplet is increased.
2022, 51(6):2033-2038.
DOI: 10.12442/j.issn.1002-185X.20210395
Abstract:
To investigate the influence of cooling rate on the solidification structure of Al-Cu binary alloy, the ingot of Al-6%Cu alloy was produced by the wedge-shaped copper mode casting. The results indicate that when the cooling rate decreases from 100 K/s to 2 K/s, the grain morphology transformation of ingot is as follows: columnar grains→mixing of columnar grains with equiaxed grains→equiaxed grains. Meanwhile, the width of columnar crystal at the ingot edge increases from 244.7 μm to 408.2 μm, the average grain size of equiaxed crystal at the ingot core decreases from 629.8 μm to 152.8 μm, and the average dendrite arm spacing increases from 10.1 μm to 52.8 μm. The parameters A and n of Al-6%Cu alloy in the empirical formula of average dendrite arm spacing and cooling rate are 78.75 and 0.41, respectively. When the cooling rate decreases from 100 K/s to 25 K/s, the morphology of eutectic Al2Cu changes from skeletal to lamellar, and α-Al near the eutectic Al2Cu is cellular. With the cooling rate increases from 2 K/s to 100 K/s, the hardness of Al-6%Cu alloy is increased from 618 MPa to 726 MPa.
To investigate the influence of cooling rate on the solidification structure of Al-Cu binary alloy, the ingot of Al-6%Cu alloy was produced by the wedge-shaped copper mode casting. The results indicate that when the cooling rate decreases from 100 K/s to 2 K/s, the grain morphology transformation of ingot is as follows: columnar grains→mixing of columnar grains with equiaxed grains→equiaxed grains. Meanwhile, the width of columnar crystal at the ingot edge increases from 244.7 μm to 408.2 μm, the average grain size of equiaxed crystal at the ingot core decreases from 629.8 μm to 152.8 μm, and the average dendrite arm spacing increases from 10.1 μm to 52.8 μm. The parameters A and n of Al-6%Cu alloy in the empirical formula of average dendrite arm spacing and cooling rate are 78.75 and 0.41, respectively. When the cooling rate decreases from 100 K/s to 25 K/s, the morphology of eutectic Al2Cu changes from skeletal to lamellar, and α-Al near the eutectic Al2Cu is cellular. With the cooling rate increases from 2 K/s to 100 K/s, the hardness of Al-6%Cu alloy is increased from 618 MPa to 726 MPa.
2022, 51(6):2039-2045.
DOI: 10.12442/j.issn.1002-185X.20210338
Abstract:
Conductive SrVO3 powders were synthesized by sol-gel method combined with subsequent heat treatment. The molar ratio of Sr:V was adjusted during the sol process. The thermal behavior of the gel was analyzed to figure out the calcination temperature in order to get the precursors without residual carbon, and then the gel was reduced in H2 to obtain the final products. The influence of temperature and molar ratio of Sr:V on the morphologies, structures and compositions was researched. The conductivity of the samples was tested by standard dc four-probe technology. The results show that when the molar ratio of Sr:V=1:1.06, the calcination temperature is 500 °C and reduction temperature is 850 °C in H2, the SrVO3 powers without the impurities of residual carbon or vanadium oxides can be obtained. The electrical conductivity of SrVO3 powders reaches 714.3 S/cm, while that of graphite powders is about 500 S/cm.
Conductive SrVO3 powders were synthesized by sol-gel method combined with subsequent heat treatment. The molar ratio of Sr:V was adjusted during the sol process. The thermal behavior of the gel was analyzed to figure out the calcination temperature in order to get the precursors without residual carbon, and then the gel was reduced in H2 to obtain the final products. The influence of temperature and molar ratio of Sr:V on the morphologies, structures and compositions was researched. The conductivity of the samples was tested by standard dc four-probe technology. The results show that when the molar ratio of Sr:V=1:1.06, the calcination temperature is 500 °C and reduction temperature is 850 °C in H2, the SrVO3 powers without the impurities of residual carbon or vanadium oxides can be obtained. The electrical conductivity of SrVO3 powders reaches 714.3 S/cm, while that of graphite powders is about 500 S/cm.
2022, 51(6):2046-2055.
DOI: 10.12442/j.issn.1002-185X.20210288
Abstract:
The hot deformation behavior of Al-xMg-2.8Zn alloys at deformation temperature of 300~490 °C, strain rate of 0.001~5 s-1 was studied by isothermal hot compression tests. After correcting the flow softening from deformation heating in stress-strain curves, Arrhenius-type constitutive equations and processing maps were used to predict and analyze the hot deformation behavior of Al-xMg-2.8Zn alloys. The results show that the flow stress increases with increasing Mg content and strain rate or decreasing temperature. According to the processing maps and corresponding microstructure of alloys, the range of optimum hot deformation parameters of alloys is determined. The range of hot deformation temperature and strain rate both extend and the instability domains extend to the zone of higher temperature and lower strain rate with increasing the Mg content.
The hot deformation behavior of Al-xMg-2.8Zn alloys at deformation temperature of 300~490 °C, strain rate of 0.001~5 s-1 was studied by isothermal hot compression tests. After correcting the flow softening from deformation heating in stress-strain curves, Arrhenius-type constitutive equations and processing maps were used to predict and analyze the hot deformation behavior of Al-xMg-2.8Zn alloys. The results show that the flow stress increases with increasing Mg content and strain rate or decreasing temperature. According to the processing maps and corresponding microstructure of alloys, the range of optimum hot deformation parameters of alloys is determined. The range of hot deformation temperature and strain rate both extend and the instability domains extend to the zone of higher temperature and lower strain rate with increasing the Mg content.
2022, 51(6):2056-2062.
DOI: 10.12442/j.issn.1002-185X.20210285
Abstract:
Based on the first-principles method of density functional theory (DFT), the segregation behavior of Si, Ni, Mn, Cr, and Mo at the NbC/fcc-Fe interface was studied, and the influence of B on the segregation behavior of alloying elements was analyzed. The results show that Cr and Mo can stably exist in the interface and NbC. Mo tends to segregate in the interface and NbC; Ni and Mn have a slight tendency to interface segregation. Mo is easy to segregate into NbC to form composite carbides. When the Mo/Nb content ratio is less than 2/3, the (Nb, Mo)C composite carbide is more stable and the binding energy is greater, which should be related to the strong electronic interaction between Mo and C and between Mo and Fe. When B is doped to the interface, the tendency of Mo and Cr to segregate to the interface is suppressed, expecially the segregation of Mo at the interface, thereby improving the corrosion resistance of the material. In addition, B can make Ni and Mn tend to be uniformly distributed in the matrix.
Based on the first-principles method of density functional theory (DFT), the segregation behavior of Si, Ni, Mn, Cr, and Mo at the NbC/fcc-Fe interface was studied, and the influence of B on the segregation behavior of alloying elements was analyzed. The results show that Cr and Mo can stably exist in the interface and NbC. Mo tends to segregate in the interface and NbC; Ni and Mn have a slight tendency to interface segregation. Mo is easy to segregate into NbC to form composite carbides. When the Mo/Nb content ratio is less than 2/3, the (Nb, Mo)C composite carbide is more stable and the binding energy is greater, which should be related to the strong electronic interaction between Mo and C and between Mo and Fe. When B is doped to the interface, the tendency of Mo and Cr to segregate to the interface is suppressed, expecially the segregation of Mo at the interface, thereby improving the corrosion resistance of the material. In addition, B can make Ni and Mn tend to be uniformly distributed in the matrix.
2022, 51(6):2063-2072.
DOI: 10.12442/j.issn.1002-185X.20210449
Abstract:
The hot deformation behavior of Incoloy 825 alloy under 60% deformation,950 ~ 1150 ℃ temperature and 0.001 ~ 1s-1 strain rate was studied by hot compression test. Based on Arrhenius equation and Zener Hollomen parameter model, the constitutive equation model of the alloy was established. The microstructure evolution of the alloy was studied by means of metallographic microscope (OM) and electron backscattering diffraction (EBSD). The results show that the percentage of DRX increases with the increase of deformation temperature or the decrease of strain rate. DRX includes both discontinuous dynamic recrystallization (DDRX) and continuous dynamic recrystallization (CDRX) during hot deformation. With the increase of deformation temperature or the decrease of strain rate DDRX increases and CDRX decreases. In addition, with the increase of temperature or the decrease of strain rate, the low angle grain boundary gradually transforms to the high angle grain boundary. Simultaneous random distribution Σ3 twin boundaries tend to homogenize, It also promotes the dynamic recrystallization.
The hot deformation behavior of Incoloy 825 alloy under 60% deformation,950 ~ 1150 ℃ temperature and 0.001 ~ 1s-1 strain rate was studied by hot compression test. Based on Arrhenius equation and Zener Hollomen parameter model, the constitutive equation model of the alloy was established. The microstructure evolution of the alloy was studied by means of metallographic microscope (OM) and electron backscattering diffraction (EBSD). The results show that the percentage of DRX increases with the increase of deformation temperature or the decrease of strain rate. DRX includes both discontinuous dynamic recrystallization (DDRX) and continuous dynamic recrystallization (CDRX) during hot deformation. With the increase of deformation temperature or the decrease of strain rate DDRX increases and CDRX decreases. In addition, with the increase of temperature or the decrease of strain rate, the low angle grain boundary gradually transforms to the high angle grain boundary. Simultaneous random distribution Σ3 twin boundaries tend to homogenize, It also promotes the dynamic recrystallization.
2022, 51(6):2073-2083.
DOI: 10.12442/j.issn.1002-185X.20210468
Abstract:
SiCp/Al composites are composed of SiC particles and aluminum alloy matrix with great performance differences. The cutting process is complex, and there are many factors affecting the processing quality, and the material simulation modeling is difficult. In this paper, a parametric modeling method of SiCp/Al composites is proposed considering the random distribution of particles, particle size, volume fraction and other factors. The removal process, cutting force, surface morphology and damage of SiCp/Al composites with different volume fraction are studied and verified by experiments. The simulation analysis and experimental results show that the parametric modeling is effective. SiCp/Al composites are characterized by severe surface damage, high cutting force, surface defects covered by substrate coating, and small actual cutting depth. The processing quality of SiCp/Al composites can not be evaluated by surface roughness alone. SiCp/Al with large particle size and high volume fraction has lower cutting force, lower specific grinding energy, worse surface quality, smaller actual cutting depth, more serious coating phenomenon and easier coating falling off. SiC particle size has an important influence on surface damage, cutting force and specific grinding energy. This paper can provide some references for the surface removal characteristics research and engineering application of SiCp/Al composite.
SiCp/Al composites are composed of SiC particles and aluminum alloy matrix with great performance differences. The cutting process is complex, and there are many factors affecting the processing quality, and the material simulation modeling is difficult. In this paper, a parametric modeling method of SiCp/Al composites is proposed considering the random distribution of particles, particle size, volume fraction and other factors. The removal process, cutting force, surface morphology and damage of SiCp/Al composites with different volume fraction are studied and verified by experiments. The simulation analysis and experimental results show that the parametric modeling is effective. SiCp/Al composites are characterized by severe surface damage, high cutting force, surface defects covered by substrate coating, and small actual cutting depth. The processing quality of SiCp/Al composites can not be evaluated by surface roughness alone. SiCp/Al with large particle size and high volume fraction has lower cutting force, lower specific grinding energy, worse surface quality, smaller actual cutting depth, more serious coating phenomenon and easier coating falling off. SiC particle size has an important influence on surface damage, cutting force and specific grinding energy. This paper can provide some references for the surface removal characteristics research and engineering application of SiCp/Al composite.
2022, 51(6):2084-2089.
DOI: 10.12442/j.issn.1002-185X.20210491
Abstract:
In this paper, a triangle of complex characteristic temperature parameters derived from glass transition temperature Tg is constructed from two perspectives of the glass-forming ability (GFA) in cooling process and glass stability (GS) in heating process. According to two complex characteristic temperature parameters, a GFA & GS criterion is derived and modified from the perspective of balanced contribution of two temperature parameters Tg/Tl and Tx/Tg, and the three temperature parameter (Tx-Tg)/(Tl-Tg) to the evaluation criterion: GTg=Tg/Tl+Tx/Tg+(Tx-Tg)/(Tl-Tg) and GTgm=Tg/Tl+(Tx/Tg)/2+((Tx-Tg)/(Tl-Tg))^0.3. Through a large number of metallic glasses, oxide glasses and cryoprotectants, the reliability and efficiency of the criteria are verified and elaborated from GFA and GS in comparison with the current criteria based on characteristic temperatures. The results show that the new criteria have wide application in the evaluation of GFA & GS, especially the modified criterion has the best performance in the evaluation of GFA & GS of metallic glasses, and can be used as a reliable criterion.
In this paper, a triangle of complex characteristic temperature parameters derived from glass transition temperature Tg is constructed from two perspectives of the glass-forming ability (GFA) in cooling process and glass stability (GS) in heating process. According to two complex characteristic temperature parameters, a GFA & GS criterion is derived and modified from the perspective of balanced contribution of two temperature parameters Tg/Tl and Tx/Tg, and the three temperature parameter (Tx-Tg)/(Tl-Tg) to the evaluation criterion: GTg=Tg/Tl+Tx/Tg+(Tx-Tg)/(Tl-Tg) and GTgm=Tg/Tl+(Tx/Tg)/2+((Tx-Tg)/(Tl-Tg))^0.3. Through a large number of metallic glasses, oxide glasses and cryoprotectants, the reliability and efficiency of the criteria are verified and elaborated from GFA and GS in comparison with the current criteria based on characteristic temperatures. The results show that the new criteria have wide application in the evaluation of GFA & GS, especially the modified criterion has the best performance in the evaluation of GFA & GS of metallic glasses, and can be used as a reliable criterion.
2022, 51(6):2090-2096.
DOI: 10.12442/j.issn.1002-185X.20210493
Abstract:
In this paper, βTitanium alloy was prepared by vacuum melting, cold deformation, and solution treatment. A six-anvil high press was used to perform high-pressure aging treatment on β-Titanium alloy, and the effects of high-pressure aging parameters on the microstructure, microhardness and elastic modulus of βTitanium alloy were studied, and the aging kinetics was analyzed. It is found that, aging pressure and time have significant effects on microstructure, hardness and elastic modulus. With the increase of pressure and time, the precipitation of α phase and martensite phase increases. The pressure and time of high-pressure aging have significant effects on the modulus of microhardness and elasticity. As the pressure increases, the microhardness first decreases and then increases, and the elastic modulus increases; as time increases, Vickers hardness and the elastic modulus first increase and then decrease.
In this paper, βTitanium alloy was prepared by vacuum melting, cold deformation, and solution treatment. A six-anvil high press was used to perform high-pressure aging treatment on β-Titanium alloy, and the effects of high-pressure aging parameters on the microstructure, microhardness and elastic modulus of βTitanium alloy were studied, and the aging kinetics was analyzed. It is found that, aging pressure and time have significant effects on microstructure, hardness and elastic modulus. With the increase of pressure and time, the precipitation of α phase and martensite phase increases. The pressure and time of high-pressure aging have significant effects on the modulus of microhardness and elasticity. As the pressure increases, the microhardness first decreases and then increases, and the elastic modulus increases; as time increases, Vickers hardness and the elastic modulus first increase and then decrease.
2022, 51(6):2097-2104.
DOI: 10.12442/j.issn.1002-185X.20210744
Abstract:
In this paper, a multi-material composite casting model with variable wall thickness structure is builded. Firstly, by simulating the filling and solidification process of A356 alloy in the multi-material composite casting mold, the filling time and temperature field results of the multi-material composite casting mold were obtained. The solidification time of zircon sand with silica sand, chromite sand with silica sand decreased progressively. The solidification time of casting is shorter at the Connection position of zircon sand with silica sand and chromite sand with silica sand, and the solidification speed of metal liquid is faster. Secondly, analysis the Electron Backscatter Diffraction Analysis (EBSD), electron microprobe analysis (EPMA), tensile strength and scanning fracture of A356 alloy casting with silica sand, chromite sand and zircon sand composite casting in gravity casting. The results show that at the same wall thickness, the grain size of chromite sand and zircon sand castings is better, the concentration ratio of Al, Mg, Si and other elements is lower, the mechanical properties are increased, and the fracture is characterized by ductile fracture. At the same time, with the decrease of wall thickness, the grain size of sand castings of the same material is fine, the concentration ratio of elements is reduce, the mechanical properties are increase, and the fracture surface presents the characteristics of ductile fracture.
In this paper, a multi-material composite casting model with variable wall thickness structure is builded. Firstly, by simulating the filling and solidification process of A356 alloy in the multi-material composite casting mold, the filling time and temperature field results of the multi-material composite casting mold were obtained. The solidification time of zircon sand with silica sand, chromite sand with silica sand decreased progressively. The solidification time of casting is shorter at the Connection position of zircon sand with silica sand and chromite sand with silica sand, and the solidification speed of metal liquid is faster. Secondly, analysis the Electron Backscatter Diffraction Analysis (EBSD), electron microprobe analysis (EPMA), tensile strength and scanning fracture of A356 alloy casting with silica sand, chromite sand and zircon sand composite casting in gravity casting. The results show that at the same wall thickness, the grain size of chromite sand and zircon sand castings is better, the concentration ratio of Al, Mg, Si and other elements is lower, the mechanical properties are increased, and the fracture is characterized by ductile fracture. At the same time, with the decrease of wall thickness, the grain size of sand castings of the same material is fine, the concentration ratio of elements is reduce, the mechanical properties are increase, and the fracture surface presents the characteristics of ductile fracture.
2022, 51(6):2105-2114.
DOI: 10.12442/j.issn.1002-185X.20210507
Abstract:
Based on Mo equivalent design, novel Ti-6Al-xMo(x = 2, 3, 4) titanium alloys was deposited by laser solid forming (LSF) from mixed Ti, Al and Mo elemental powders, and the microstructure and room temperature tensile properties of the alloys were investigated. The results showed that the solidification microstructure of the three alloys presents a coarse columnar grains growing along the direction of <100>, and the top is composed of equiaxed grains. With the increase of Mo content, the average width of the columnar grains decreases, and the thickness of the equiaxed grains layer increases gradually. The microstructure in primary β grains is composed of primary α lath and retained β phase, and there also exits grain boundary α and α colonies. With the increase of Mo content, the width and area ratio of primary α lath decrease. When the Mo content increases to 4 wt.%, the secondary α phase appears in the grain. Moreover, 12 α variants were found in all the three components by Electron Backscatter Diffraction (EBSD) analysis, and the variation was dominant. In terms of mechanical properties, the strength and hardness increase with the increase of Mo content while the elongation decreases. By contrast, Ti-6Al-2Mo and Ti-6Al-3Mo have the very good tensile properties of 962 MPa tensile strength and 11.5% elongation, and 982 MPa tensile strength and 9.2% elongation, respectively.
Based on Mo equivalent design, novel Ti-6Al-xMo(x = 2, 3, 4) titanium alloys was deposited by laser solid forming (LSF) from mixed Ti, Al and Mo elemental powders, and the microstructure and room temperature tensile properties of the alloys were investigated. The results showed that the solidification microstructure of the three alloys presents a coarse columnar grains growing along the direction of <100>, and the top is composed of equiaxed grains. With the increase of Mo content, the average width of the columnar grains decreases, and the thickness of the equiaxed grains layer increases gradually. The microstructure in primary β grains is composed of primary α lath and retained β phase, and there also exits grain boundary α and α colonies. With the increase of Mo content, the width and area ratio of primary α lath decrease. When the Mo content increases to 4 wt.%, the secondary α phase appears in the grain. Moreover, 12 α variants were found in all the three components by Electron Backscatter Diffraction (EBSD) analysis, and the variation was dominant. In terms of mechanical properties, the strength and hardness increase with the increase of Mo content while the elongation decreases. By contrast, Ti-6Al-2Mo and Ti-6Al-3Mo have the very good tensile properties of 962 MPa tensile strength and 11.5% elongation, and 982 MPa tensile strength and 9.2% elongation, respectively.
